Name |
Unit |
Technical Specification | |||||||
|
Matching Cupola |
Ton/Hour |
３ |
５ |
７ |
１０ |
１５ |
| ||
|
Skip Bucket |
Capacity |
３ |
0.285 |
0.4 |
0.6 |
1.15 |
1.27 |
| |
|
Max. Loading Capacity |
kg |
450 |
750 |
1000 |
1500 |
2300 |
| ||
|
Bottom-Opening Mode |
|
|
|
|
|
|
| ||
|
Trolley |
Normal Speed |
m/second |
0.25-0.34 |
|
0.25-0.4 |
0.25-0.4 |
0.25-0.4 |
| |
|
Circulation Times |
second/hour |
26 |
26 |
26 |
26 |
26 |
| ||
|
Track |
Mm |
900 |
950 |
1120 |
1340 |
1390 |
| ||
|
Wheel Distance |
Mm |
890 |
940 |
1110 |
1330 |
1380 |
| ||
|
Winch |
Max. Pull |
ton |
1.5 |
2.5 |
3.5 |
5 |
5 |
| |
|
Roller Mode |
|
double roller | |||||||
|
Working System |
ＪＣ |
40% |
40% |
40% |
40% |
40% |
| ||
|
Decelerator |
|
ZQ35-40-VZ |
ZQ50-50-VIZ |
ZQ65-50-VIA |
| ||||
|
Motor |
Model |
|
YZR160M26 |
YZR160L-6 |
YZR180L-6 |
YZR200L-6 |
YZR200-6 |
| |
|
Power |
KW |
7.5 |
11 |
15 |
22 |
22 |
| ||
|
Steel Rope |
|
6×37-11-185 -1 |
6×37-13-185-1 |
6×37-15.5-170-1 |
6×37-17.5-185-1 |
6×37-19.5-200-1 |
| ||
